* Weight: 24 lbs. / 10.9kg
Type: Rechargeable, sealed lead-acid battery. 4 Ah, 12 V nominal.
Charge Time: 2 hours to 90% of full capacity. 18 hours to 100% capacity. Repeated charging to less than 100% will reduce the useful life of the battery.
Capacity: 2.5 hours monitoring or 50 full-energy discharges or 1 hour monitoring and recording.
AC input: 100 to 230 VAC +/- 15%, 50/60 Hz.
Battery Indicators: Illuminated LED indicates battery is charging. Low Battery message appears on the monitor.
Waveform: damped sinusoidal.
Output energy (delivered): 2,3,5,7,10,20,30,50,70,100,150,200,300, and 360 joules.
Charge control: push-button on apex paddle and on front panel.
Charge time: less than 5 seconds to 360 joules with a functional battery installed.
Charge done indicator: display indicates available energy, charge-done light on apex paddle, charge done tone.
Synchronizer: SYNC message appears on the monitor and is annoted periodically on the recorder while in synchronous mode. An audible beep sounds with each detected R-wave, while a marker on the monitor and sync mark on the recorder strip indicate the discharge point.
Paddles: standard paddles are anterior / anterior. Adult electrodes (83 cm sq) slide off to expose pediatric electrodes (21 cm sq). Paddle cord is 10 feet (3m). Full range of internal paddles are available.
