Cone, Collimation Plate for 18 x 20 cm, Compression paddles (Normal and Spot), Retractable cord, Film marking device.
As an AEC Monitors the X-rays transmitted through the breast, it increases the diagnostic capability.
3 Step anatomical programming
Type of Machine:
High frequency 40 KHz. x-ray generator
Maximum mA Output:
Maximum KV Output:
X-Ray Tube :
Rotating anode x-ray tube.
" -Small focus = 0.1 mm - Large focus = 0.3 mm"
22 to 35 KV in steps of 0.5 KV each.
1 mAs to 700 mAs
LCD display on control panel, LCD display on the stand
"Single phase, 230 volts ± 10%, AC, 50 Hz, 15 amps. with independent earthing on the wall socket."
