Name: APS-LAF-011 Horizontal Laminar Air Flow 3*2*2 Ft
SKU: APS LAF 011 Horizontal Laminar Air Flow 3*2*2 Ft-1576646699
Availability: InStock

Condition
- New
Brand
- APS
Model
- APS-LAF-011
Year Of Manufacture
- 2019
Country of Manufacture
- India
Warranty(In Months)
- 12
Description
- Laminar flow cabinet (horizontal / vertical) designed so as to meet the requirements of US federal standard 209 B (BS 5295) providing particle free air to meet class 100 conditions. The unit is fitted with pre-filter and HEPA filter. Air is drawn through pre-filter and is made to pass through highly effective HEPA filters having efficiency rating as high as 99.99% with cold DOP & 99.97% with hot DOP thus retaining all air-borne particles of size 0.3 micron and larger. Using a dynamic machine, the blower and motor assembly is statically and dynamically balanced ISI marked motor of 1/4 HP capacity operates with minimum noise level less than 60 dB on a Scale. The working area is illuminated by fluorescent lighting fitted to the unit. Height of the working table provides comfortable “SIT DOWN” working position for the operator.

Length(cm)
Width(cm)
Height(cm)
Spares Availability
- Yes
Battery Backup(min)
Amperage(amp)
Delivery Duration
- 15 Days
After Sale Service
- Pan India
Other Specifications
- * Size (feet) : 3' x 2' x 2' * Size of HEPA filter : 3' x 2' x 6” * No of HEPA filters : 1 * No of pre filters : 1 * Illumination : 1 x 20 W * UV Germicidal light : 1' x 1½' Sailent features:- * The cabinet are fabricated of thick mild steel / stainless steel laminated by cold rolled steel duly powder coated or SS as per requirement. * Side panels are made out of thick transparent plexus glass / acrylic sheet duly framed. * High efficiency pre filter. * Pressure manometer to gauge the pressure drop in the unit.
